Code: Select all

-- AA is the FROM-angle (optional)
-- K is the CHANGE (pos=rightTurn or neg=leftTurn) to that angle
on turnBY K, AA
   if AA is empty then put the angle of widget "TURTLE" into AA
   add K to AA; put AA mod 360 into AA; if AA < 0 then add 360 to AA
   set the angle of widget "TURTLE" to AA
end turnBY

-- x0 and y0 are the start points (optional)
-- R is the length to go forward in the turtle's path
on forwardzBy R,x0,y0
   if x0 is empty then put item 1 of the loc of widget "TURTLE" into x0
   if y0 is empty then put item 2 of the loc of widget "TURTLE" into y0
   if there is no grc "TurtleCurve" then createTurtlePath "TurtleCurve"
   put the angle of widget "TURTLE" into AA
   add 90 to AA --> so that the angle zero is at high noon
   put round(x0 - R*cos(AA*pi/180)) into newX
   put round(y0 - R*sin(AA*pi/180)) into newY
   put the points of grc "TurtleCurve" into PTS
   put cr & (newX,newY) after PTS
   put PTS into fld "LYNES"  --> in case you wish to edit points
   set points of grc "TurtleCurve" to PTS
   set hilite of widget "TURTLE" to true -- just for fun
   move widget "TURTLE" to line -1 of PTS in 1 second
   set hilite of widget "TURTLE" to false
end forwardzBy

on createTurtlePath gg
   create grc gg; set style of grc gg to "polygon"
   set layer of widget "TURTLE" to "top"
   put the width of widget "TURTLE" into twd
   set foreColor of grc gg to "yellow"  --> adjust here
   set lineSize of grc gg to twd        --> adjust here
   set blendLevel of grc gg to 62       --> adjust here
end createTurtlePath

Code: Select all

-- PENTAGON: Has 5 turns of 360/5 = 72 degrees and
-- 5 sides of equal length, say L = 200
on mouseUp
   if there is no grc "TurtleCurve" then createTurtlePath "TurtleCurve"
   set loc of widget "TURTLE" to the loc of this card
   set the angle of widget "TURTLE" to 0
   set points of grc "TurtleCurve" to the loc of this card -- start point
   turnBy 54 -- startangle, half the vertices angle
   repeat 5
      turnBy 72; forwardzBy 200
   end repeat
   turnBy -54 -- back to angle zero
end mouseUp
